Quartz Tube Wash Systems
The NexChem Quantum Series™ Tube Wash Systems are high-performance acid cleaning solutions engineered for precision cleaning of quartz tubes and rods — available in both Vertical and Horizontal configurations to match your process requirements. Designed for advanced manufacturing environments, Quantum Series systems deliver controlled acid blending, recirculation, and automated processing — while reducing chemical consumption, DI water usage, and overall effluent costs.Whether your application requires vertical immersion dynamics or horizontal handling for larger tubes and rods, the Quantum platform provides the flexibility, control, and reliability demanded in high-purity environments.
Independent HF & Nitric Storage - Precise, metered blending with flexibility for alternate chemistries
Integrated DI Pre-Mix Reservoir - Controlled concentration management for consistent etch performance
Recirculating & Filtered Acid Loop - Extended chemical life and reduced operating costs
Optional Concentration Monitoring - Real-time measurement with automated spiking capability
Uniform Spray Manifold Design - Conformal etch coverage across full tube surface
Programmable Multi-Step Process - Light Etch → Rinse → Dry
The Quantum Series Vertical Tube Wash combines intelligent chemistry management with durable mechanical design to deliver repeatable, high-purity cleaning performance. Contact NexChem Systems to configure your Quantum VTW solution.
System Architecture
Quantum systems are engineered from the ground up as process-grade platforms.
Spray Technology
Engineered spray nozzle design for conformal coverage and optimized spray patterns for consistent surface exposure.
Chemical Delivery
Dedicated chemical supply architecture with metered chemical delivery for precise control, designed to minimize chemical usage while maintaining uniformity.
Controls & Automation
PLC-based control system with recipe management for process repeatability and configurable timing, flow, and sequence parameters.
Materials & Mechanical Design
Quartz-compatible, acid-resistant materials throughout, with configurable tube orientation (horizontal or vertical) and adaptable to varying tube diameters and lengths. Designed for ease of service and long-term reliability.
Safety & Compliance
Quantum systems are designed with safety as a core requirement:
Integrated safety interlocks for chemical handling
Controlled chemical delivery and containment
Designed for use in fab and high-purity laboratory environments
Ready to configure your Quantum Series?
Submit a Request for Quote to start a conversation with our application engineers. We'll help you find the right configuration for your specific process needs.
